Web online application Smart Street Lighting by the Loop Control Circuit Panel

Detailed of the PLC & LoRa Technology showing on 93km Shen Zhen Outer Ring Expressway Street Lights & Tunnel

Light Groups:

The CH-J106 Centralized Loop Controller is independently developed by our company. Aimed for Highway, Tunnel, industry lighting for Warehouse and Factory, Buildings and tations, etc., to control the power supply of lighting fixtures through a human-machine interface, to collect data and monitor the status of the lighting fixtures.

 The management of traditional lighting fixtures in factories, warehouses, buildings, and stations mostly adopts special personnel manual control and special personnel inspection status, which not only takes up a lot of manpower and material resources, but also has problems such as inadequate management and untimely management. For example, special personnel are required to switch lights every day, Even if time-space equipment such as time controllers and theodolites are used, it still cannot solve multi-time management, abnormal weather operations such as cloudy days, accidents and other incidents, and equipment operations on site are still required. Another example: rigid control methods, lighting scenes, only relying on personnel inspections to find faulty equipment, and unable to provide managers with timely and reliable operating data. In response to these problems, our company has launched this lighting control equipment that integrates data collection, fault monitoring, data processing, local manual control, remote control, automatic operation by settings, theodolite, and sensor linkage.

The device has multiple interfaces: Reserved industrial bus RS-485 and RS-232, interaction with an Industrial Touch Screen, Ethernet Port, Lighting Control connector, communication with sub-control boxes, and sensors (such as Illumination sensor, etc.) communication interface. The main function of the device is to link and expand the control module through many interfaces, collect, feedback data, and issue control command and other centralized management and control functions.

The main communication interface communication performance are as follows:

1. The communication distance of the RS-485 industrial bus can reach 2 kilometers without relay, and the actual measurement in the tunnel can reach 1 kilometer; 7-level gateways can be set up in the scene, and the longest distance can be up to 7 kilometers per gateway. km, the device capacity in the gateway reaches 255;

2. LoRa communication interface, the communication distance can reach 2 kilometers without relay, the actual measurement can reach 1 km, and the communication distance can reach 10 kilometers with relay.
